PrepFAST Bespoke design options
A1-envirosciences automated chemistry division provides a unique portfolio of cutting-edge technologies for laboratory automation. Focused on the goal of eradicating sample preparation and analytical bottle necks, our dedicated team can provide the answer to problematic laboratory automation obstacles, with a range of bespoke automated products and solutions.
If your off-the-shelf instruments do not provide the solution to your current or future automation requirements, contact our team of experts who can offer advice on an alternative, customized solution that meet your demands of your laboratory
Key features
- Automated sample preparation such as filtration, sub sampling, mixing, etc
- Single and multi-probe options that can also eliminate contamination for oil dilution
- Flexible customizable software
- With over 200 standard sample racks available – virtually any tube size can be accommodated. Custom made racks are also available
- Aqueous and non-aqueous liquid handling possible
- Automatic sample pipetting with powerful liquid handling capabilities
- Unrivaled application flexibility with the potential to interface, integrate and control other laboratory instrumentation, IC, ICP-MS, UV-vis, LC and more.
- Full LIMS communication
- PrepFAST sample preparation options can be combined with the other high throughput automated systems from a1-envirosciences.
Application
The prepFAST can be used to address a variety of liquid handling problems:
- Dilution of oils for ICP MS/OES.
- Liquid sample preparation for techniques such as liquid and Ion Chromatography.
- Liquid dispensing, subsampling and mixing.
- Multi sample analysis with the ability to prepare samples whilst analyzing
- Automated sample filtrations
Industry
Environmental
Industrial
pharmaceutical
Petrochemical
Energy
Food
Product details
Specifications
- Capacity (Flow through): 350 x 15ml disposable tubes for model GX215 280 x 15ml disposable tubes for model GX271
- Capacity (Flow DIP): Up to 170 x 50ml disposable tubes for model GX215, Up to 70 x 50ml disposable tubes for model GX271
- Measurement time: < 2 to 10 minutes depending on configuration
- Typical sample types: Water, oils, lubricants,
- Sample volume (flow through): < 15ml
- Footprint: GX215 – 91.4 (w) x 61 (d) x 55.8 (h) cm / GX271 – 59.7 (w) x 54.1 (d) x 57.1 (h) cm
Software
PC Software
- TitreFast Lite
- Common Windows 7 or 10 64 bit interface or higher
- Easy LIMS import of sample schedules and export via LIMS for reporting
- MS Excel Reporting
PC specification
- Pentium 4 with 1GHz or better, >1 GB RAM, 200GB hard disk
- one free RS232 port
- Windows 7 Prof 64 bit, Windows 10
- 1024×768 or high resolution monitor
- Requires Microsoft Excel or Office installed.
- please send the PC to a1-envirosciences prior to installation
